Switch Nest Diverter RGNS-36C-V

Add to List
  • Switch nest diverter
  • Provides 31″ (78.7cm) of coverage
  • Easily installed/attached with super strap banding
  • Best used in combination with Pole Top Cap if there is an exposed pole top above the equipment

Install support

Nest Diverter Installation with Super Straps, example

Play Video

Super Strap Tutorial

Play Video

Product Description

This Switch Nest Diverter maximizes a sloped shape that effectively deflects sticks and deters nesting activity in the covered area, even when past nesting activity has occurred. Nest diverters are especially appropriate for ospreys and eagles, as well as crow and raven nesting prevention, and are best used in combination with nesting platforms to provide a safe space for breading and nesting away from the danger zone.

Bird nests on electrical structures can cause power outages, fires, and avian electrocutions so it is best to prevent nesting activity before it begins.

The RGNS-36C-V provides 31″ (78.7cm) of coverage and is banded into position. Power Line Sentry Super Strap Banding recommended.

It’s UV resistant/weather resistant material is engineered to maintain performance in harsh/extreme conditions for the longevity and features a UL 94 V-0 flame retardant design.

Additional Information

Flame Retardant Rating

V-0

Material

RPVC

Nest Prevention Structure Application

Switch equipment

Wind Resistance Rating

120 mph

Properties

ASTM D-149 Dielectric Strength

>50kV

ASTM D-638 Comparative Tracking

>500V

ASTM G-26 Accelerated Weather Testing

>1000 hrs

UL 746c Outdoor Weatherability

F1

UL-94 Flammability

V-0 / 5VA
